The Compact INS2500 is a specific model of switch-disconnector manufactured by Schneider Electric. Here's an overview of this device:

Compact INS2500 Switch-Disconnector:

1. Rated Current: The "2500" in Compact INS2500 typically refers to its rated current capacity, which is 2500A. This indicates the maximum continuous current that the switch-disconnector can safely carry under normal operating conditions.
2. Functionality: The Compact INS2500 is designed to disconnect electrical circuits from the power supply for maintenance, repair, or safety purposes. It provides a means of isolation to ensure that circuits can be safely worked on without the risk of electrical shock or damage.
3. Switching Capability: As a switch-disconnector, the Compact INS2500 can both manually switch circuits on and off and disconnect them from the power supply. This dual functionality allows for convenient operation and maintenance of electrical installations.
4. Compact Design: Similar to other devices in the Compact series, the INS2500 is designed to be space-efficient, making it suitable for installation in switchboards or electrical enclosures where space is limited.
5. Compliance: The Compact INS2500 complies with relevant industry standards and regulations for safety and performance, ensuring that it meets the necessary requirements for use in electrical installations.
6. Applications: The Compact INS2500 is suitable for a wide range of applications, including industrial, commercial, and residential settings. It can be used in distribution boards, switchgear, control panels, and other electrical enclosures where reliable isolation of circuits is required.
7. Safety Features: The INS2500 may include various safety features, such as padlockable handles, door interlocks, and visible isolation status indicators, to enhance safety during operation and maintenance.
8. Durability: Schneider Electric products are known for their durability and reliability. The Compact INS2500 is designed and manufactured to withstand harsh operating environments and provide long-term performance.

Overall, the Compact INS2500 switch-disconnector is a reliable and versatile device used for isolating electrical circuits in various applications. Its compact design, robust construction, and safety features make it an essential component in electrical distribution systems.
