The Acti 9 ARA iC60 is an automatic recloser auxiliary designed for use with the iC60 circuit breakers from Schneider Electric. This device enhances the functionality of the circuit breakers by providing automatic reclosure after a fault, which can significantly improve the reliability and continuity of electrical service.

Key Features of Acti 9 ARA iC60

1. Automatic Reclosure:
   • Automatically recloses the iC60 circuit breaker after a fault.
   • Reduces downtime by restoring power without manual intervention.
   • Typically allows for multiple reclosure attempts before locking out to prevent damage.
2. Compatibility:
   • Specifically designed for seamless integration with iC60 circuit breakers.
   • Suitable for use with single-pole, double-pole, and multi-pole iC60 breakers.
3. Safety and Protection:
   • Includes safety features to ensure reclosure only occurs under safe conditions.
   • Provides protection against temporary faults, which can be cleared without manual reset.
4. Adjustable Settings:
   • Allows configuration of the number of reclosure attempts and the time interval between attempts.
   • Settings can be adjusted to match specific application requirements and operating conditions.
5. Remote Monitoring and Control:
   • Can be integrated with remote monitoring systems for status updates and control.
   • Facilitates remote diagnostics and maintenance planning.

Applications

1. Power Distribution Networks:
   • Ideal for use in power distribution networks where temporary faults are common.
   • Helps maintain continuity of service and reduces the need for manual resets.
2. Industrial Facilities:
   • Enhances the reliability of electrical systems in factories, warehouses, and industrial plants.
   • Minimizes production downtime due to electrical faults.
3. Commercial Buildings:
   • Suitable for use in office buildings, shopping centers, and other commercial facilities.
   • Ensures a consistent power supply and reduces maintenance efforts.
4. Infrastructure and Utilities:
   • Beneficial for critical infrastructure such as hospitals, data centers, and utilities.
   • Supports the continuous operation of essential services.

Installation and Configuration

1. Installation:
   • The ARA module is mounted directly onto the iC60 circuit breaker.
   • Simple and straightforward installation process with minimal additional wiring.
2. Configuration:
   • Initial setup involves configuring the reclosure settings, such as the number of attempts and time intervals.
   • Configuration can be done using the controls on the device or via software tools provided by Schneider Electric.
3. Integration:
   • Can be integrated with building management systems (BMS) and other automation systems for enhanced control and monitoring.
   • Supports various communication protocols for seamless integration.

Advantages

• Improved Service Continuity: Automatically restores power after temporary faults, reducing downtime.
• Enhanced Reliability: Provides consistent and reliable operation of electrical systems.
• Cost Savings: Reduces maintenance costs and the need for manual resets.
• Safety: Ensures safe reclosure conditions and protects the system from damage due to repeated faults.

For detailed technical specifications, installation guides, and configuration manuals, refer to the product documentation provided by Schneider Electric or visit their official website.
